10.1″ Quad Split Monitor 4X CCD Rear View Backup Camera System Bus Truck RV

10.1″ Quad Split Monitor +4X CCD Rear View Backup Camera System Truck RV
HD 10.1″ TFT LCD 4-SPlit Screen Quad Rear View Backup Parking Monitor
+Remote Controller+Sunshade Cover
+4x 800TVL 4PIN Metal Case 18 IR LEDs Night Vision Waterproof
REAR VIEW Backup Sharp CCD Color Camera Mirror Image 120 Degree
+4x 4Pin 10M / 33Ft Video Cable & Power Cable
12V-24V Compatitable
Features:

This item is 12V-24V version.
There are 11 different modes to display, meeting different needs.
The CCD image sensor outputs digital signals that improve picture’s clarity, color contrasting and sharpness to a better level than CMOS camera.
With its 18 individual Infrared (IR) LED, CCD camera shows clear images in low light conditions especially at night circumstances.
This heavy duty CCD camera is hard metal cased, waterproof and mud proof. Can last for a longer time without heating up, providing rearview at all time.

The advantages of 4-pin connector cable:
One cable solution deals with both power and singal transmission. No power cable is needed
to connect cameras. Special thick hard wire can shield vehicle’s circuit interference better
than normal AV cable.

The difference between CCD and CMOS camera:
CCD camera has sharper pictures. It sharpens the focus of picture, making it as real as possible.
CCD lens Makes clear night vision even in a low light environment.
18 infrared lamp used in the low light condition
You can easily adjust the angle at Multi-level
120 degree angle lens, ensure car’s rear side for effective reversing and parking operation
100% complete waterproof
12V-24V input
This item is for 12V-24V power input vehivles

Monitor cable is approx. 2.5m (7.4ft) long.
Video cable is 10m(33ft) long.(Extra length video cable is available for purchase, please contact us for details.
Specifications:
Monitor:
Style: 10.1” TFT LCD Color Quad Monitor
Color System: PAL/NTSC (AUTO)
Display Resolution: 1024(H) x 600(V)
Video Input: 4 Channel
Brightness: 450(cd/m2)
Operating temperature: -20 C – +70 C
Voltage: DC12V-24V
Camera:
Style: 4 PIN
Sensor: 1/3 “SHARP Color CCD
Horizontal Resolution: 800TV Lines
Effective pixel NTSC : 910(H) x 892(V)
Mimimum Illumination: 0LUX(18 IR LEDs for night vision)
View angle: 120
Video Output: 1.0Vp-p75
Voltage: DC12V-24V
Waterproof grade: IP68
Shockproof: 10G
Dimension: 89(W) x 53(H) x 48(D) mm
